X-Ray Inspection System : XIS-3000
PACKAGE & BULK : Bulk Ingredient Inspection
Single X-ray beam with top-down method, which is specialized in the inspection of foreign substances in bulk products before packing
Applicable Products
Applicable Products
-
Foreign substances inspection system in dried agricultural and bulk form products
Grain, Dehydrated vegetable, Bulk food
Main Functions
Main Functions
-
Convenient program operation
- Easy to operate with graphical sensitivity setting menu
- User-friendly program structure and data management program -
Always open and ready to meet customer requirements
- Offers customized services depending on each customer’s usage environment
- Develops and applies inspection algorithm suitable for each product’s characteristics -
A system applied with patented technology for network-integrated operation
- Remote control and entire image storage solutions on investigated products
Technical Specification
Inspectable Object Size (mm)
| H | W |
|---|---|
| 245 | 220 |
| 210 | 240 |
| 180 | 261 |
| 150 | 282 |
| 120 | 302 |
| 90 | 323 |
| 60 | 344 |
| 30 | 364 |
| 0 | 375 |
X-Ray Object Image
XIS-3000 SPECIFICATIONS
| Model | XIS-3000 |
|---|---|
| Dimension (mm) | 1,985(W) x 915(L) x 1,790(H) |
| Power Consumption | 1.5kW |
| Weight (kg) | 560 |
| Conveyor Belt Width (mm) | 420 |
| X-Ray Inspection Max. Speed (EA/Min) | – |
| Cooling Type | FAN (Standard) or Air-Conditioner (Option) |
| Display | 17″ LCD Touchmonitor |
| Conveyor Height (mm) | Apply the height requested by the client |
| X-Ray Output | 80kVp / 100kVp / 150kVp |
| X-Ray Leakage | Less than legal limit |
| Detector Type | Linear Sensor |
| Pixel Size (mm) | 0.4 |
| Software | intellisense X-Ray Inspection System Software |
| Operating System | Windows Embedded OS |
| Power Supply | 220~230VAC / 50~60Hz |
| Operating Environment | Ambient temperature : 5~35°C / Humidity : 30~80% RH (No Condensing) |
