| Dimension (mm) |
600(W) x 640(L) x 1,450(H) |
800(W) x 860(L) x 1,580(H) |
900(W) x 920(L) x 1,725(H) |
| Power Consumption |
0.5kW |
1.0kW |
1.5kW |
| Weight (kg) |
200 |
270 |
350 |
| Conveyor Belt Width (mm) |
270 |
270 |
410 |
| X-Ray Inspection Max. Speed (EA/Min) |
600 |
400 |
400 |
| Cooling Type |
FAN (Standard) |
FAN (Standard) or Air-Conditioner (Option) |
FAN (Standard) or Air-Conditioner (Option) |
| Display |
12" LCD Touchmonitor |
15" LCD Touchmonitor |
17" LCD Touchmonitor |
| Conveyor Height (mm) |
Apply the height requested by the client |
| X-Ray Output |
80kVp / 100kVp / 150kVp |
| X-Ray Leakage |
Less than legal limit |
| Detector Type |
Linear Sensor |
| Pixel Size (mm) |
0.4 |
| Software |
intellisense X-Ray Inspection System Software |
| Operating System |
Windows Embedded OS |
| Power Supply |
220~230VAC / 50~60Hz |
| Operating Environment |
Ambient temperature : 5~35°C / Humidity : 30~80% RH (No Condensing) |
